3 PCS Double Block and Bleed Ball Valve 3/4” 600LB RF LF2 API608

Key Specifications / Features

Model No.: Hits: 0

3/4” 600LB DBB Ball Valve is made according to API 608 standard. The valve body is made of A350 LF2. It has the structural characteristics of Double Ball, Floating Ball, Full Bore, with Vent Valve (Needle Valve), Leakage Rate ISO 5208 Rate A, NACE MR0175 Compliant, Corrosion Allowance: 3 mm, Fire-Safe per ISO 10497, Anti-Static, Blowout-Proof Stem, Lever Operated with Locking Device. Its connection mode is RF. And it has LEVER OP. operation mode.

Request a quote

Tags:

Next: Return to List

Previous: 4"x3" 150LB Forged Floating Ball Valve LF2 RF API6D

Detail Information

Product Parameters

Type	DBB Ball Valve
Size	3/4”
Pressure	600LB
Connection	RF
Operation	LEVER OP.
Body Material	A350 LF2
Design Norm	API 6D
End to End	Manufacturer standard
End connection	RF
Test & Inspection Code	ISO 5208
Temperature	-46 ~ 200°C
Applicable Medium	Water, Oil and Gas

Features

1.3 PCS Double Block and Bleed Ball Valve 3/4” 600LB RF LF2 API 608 provides true double isolation with bleed function, ensuring safe maintenance and zero leakage in critical pipeline systems (double block and bleed ball valve 600LB LF2).
2.LF2 Low Temperature DBB Ball Valve delivers reliable sealing performance and easy installation with 3-piece design, ideal for low-temperature oil & gas applications (3/4 inch DBB ball valve RF API 608).
